Parameter

Value

General parameters

Operating temperatures, ^oC

-20 to +55

Humidity, %

10-100

Noise level

<65dB(A)@1m

Warranty

24 months

Protection class

IP55

Dimensions, LхWхH, mm (mobile)

711х600х11182

Battery capacity

50Ah

Input parameters

Input voltage, VAC

220-230, 1 phase, 3 wires (1P+N+PE)

Input frequency, Hz

50/60 ±5%

Inrush current

soft start

Output parameters

Number of outputs

1

Current (continuously), A

≤ 300 (up to the discharge)

Rated output voltage, VDC

≤ 28.5

Output voltage stabilization accuracy, V

±0.5

Output voltage ripple factor, V

≤2

Coefficient of efficiency, %

97

Line drop compensation

automatic

Overload rating

Up to 1200 A – ≥ 2 sec

Protection

over/under voltage at input/output

overload

overheating

short circuit at input/output

Documentation

User Manual + Service Manual; Spare Parts Catalogue; Passport; Warranty Certificate
