Saudi Arabia VFR Aeronautical Chart – ICAO Chart
Edition: 2026

Special features for this region:

    Significant points (border crossing points)
    TMA terminal control area
    VAR magnetic variation
    VOR radio navigation aids
    Danger areas



All Rogers Data VFR ICAO charts 1000k are designed to the following criteria:

    Saudi Arabia South aeronautical chart on a scale of 1:1.000.000
    According to ICAO Annex 4; EU Commission Regulation; AIP
    Clear representation of the ATS airspace structure
    Detailed highly sophisticated terrain map with shading and relief
    Airports, aerodromes and heliports with additional information
    Radio Navigation Aids with name, frequency and morse code
    Compulsory reporting points, reporting points on request, significant points (border crossing)
    Danger- and restricted areas
    Obstacles or group of obstacles
    Minimum Grid Area Altitude
    Isogonic line model with magnetic variation



RDtech® Lamination Coating Technology:

All Rogers Data VFR charts will be issued with our brand-new and unique RD tech® lamination coating technology.
The great benefit of the new and unique RDtech® technology is that all Rogers Data charts are almost impossible to tear and can be folded many times. They are designed to withstand excessive use while also being safe and easy to use.
Rogers Data VFR charts have a special laminate with a silk-matt finish that prevents reflections from the sun.
Tests have confirmed resistance at temperatures between -20°C and +80°C. The suitability for use in arctic temperatures or in hot cockpits has been proven.
They can be written on using our optimized permanent RDtech® pens. Those markings can be removed residue-free with our optimized RDtech® spray or RDtech® cleaning tissue. You can repeat all of this several times. Your laminated RDtech® VFR aeronautical chart always looks like new.

Try out our Rogers Data VFR aeronautical charts!
Enjoy flying Rogers Data VFR charts with the brand-new and unique RDtech® technology.
